Cladding Modeling & Drawing Services

: Cladding Modeling & Drawing Services

Accurate cladding drawings reduce wastage and site rework. We model and detail every panel, subframe and fixing, so materials are fabricated correctly the first time.

Get a quote for your cladding package

Cladding systems we cover

  • ACP/ACM
  • Metal and Zinc
  • HPL
  • Stone
  • Terracotta
  • Fibre cement
  • Rainscreen and louvre systems

Deliverables

  • 3D cladding model with subframe
  • Setting-out drawings and panel layouts
  • Panel fabrication drawings with folding and routing details
  • Panel schedules, cutting lists and material take-offs
  • Interface details at windows, parapets and corners
